| Humidity Controller | |
|---|---|
| Warehouse: | CNBM Shanghai NO.6 |
| Product code: | SN_A6E963C76AEA |
| Mini Order Qty: | 1 |
| Type: | |
| Drawing No.: | |
| Quantity: | - + EA |
| Remaining : | 100 |
| Shipping Cost: | To be confirmed |
| Add to Cart Add to Wishlist( 0 Adds) | |
Quick Details,
Customization: yes
Brand: TOKY / East Kawasaki Instrument
Model: TE4-RB10W
Control Type: Temperature
Control mode: intelligent temperature control regulator
Temperature range: -199 ~ 1250 (℃)
Hole Size: 45W × 45H (mm)
Mounting: flush mounting
Output signal: contact output / solid state output / SCR control output (mA)
Operating voltage: AC110V/220V 50Hz (V)
Dimensions: 48W × 48H × 100L (mm)
Weight: 0.3 (Kg)
Measurement error: 0.5% (℃)
Product Features:
1. simple, economical and practical
2. Mechanical equivalent of heat galvanic / RTD universal input.
3. with a self-tuning PID control.
4. RELAY, SSR, SCR and other control output options.
5 choose from a variety of family dimensions.
Other parameters of the products :
|
Characteristics |
Specific parameters |
|
Input Signal |
Thermocouple: K, E, J, T
Thermal resistance: PT100, CU50, CU100 software optionally available universal input |
|
Control range |
-199℃～1820℃ |
|
Control mode |
R: Relay Control S: solid state relay control K: SCR control P: Time proportional PWM control |
|
Auxiliary control |
One relay alarm output limit |
|
Sampling and control cycle |
≤0.5S |
|
Accuracy class |
±0.5%FS |
