Quick Details:

Model: JYB/KS-I, JYB/KS-II

Structure type: straight

Switch type: normally open

Rated voltage: 220/380 (V)

Rated current: 5-10 (A)

Working stroke: 25

Over stroke: 35

Scope of application: conveyor belt

Product certification: Ce

Custom processing

Life: 500000 (Times)

Temperature range: 80 (c)

Protection grade: IP65

Rated current: 10 (A)

Rated voltage: 380 (V)

Applications:

1. conventional belt conveyor

2. underground, in support of belt conveyor

3. the ship loading and unloading system

4. stacker / reclaimer conveyor

5. incline and shuttle conveyor

6. crane and excavator boom limit

7. skirtfeeder/ conveyor apron feeder

8. heavy duty limit switch

9. special processing, nickel and stainless steel roller

10. auxiliary flag alarm

11.  wrench (for a cover)

Work Environment

1. ambient temperature:. -40 ℃ ~ 60 ℃
2. Relative humidity less than 85%
3. Altitude less than 2000m
4. life: 100,000 switching operations
5. insulation voltage:. AC1000 test 1 minute
6. contact capacity:. ≤ AC380 ≤ 3A
7.  Protection class:. HFKPT1 IP55

Product Features


1. universal mounting design allows free anti-bias switch installed in the conveyor stringers top or bottom.
2. Rugged cast aluminum housing, protection standards NEMA4, special environment optional special surface treatment.
3. piece cover for easy wiring and adjustments.
4. can be removed without dismantling the operating lever cover.
5. action rod bearing Rated speed 5000 rev / min, suitable for belt speed is less than 6.35 m / s.
6. normal operating lever angle adjustment range is 22.5 degrees.
7. alarm contact angle between the normal operation of 10 degrees, the normal operation of the contact angle of 20 degrees down.
