| Vibration Sensor | |
|---|---|
| Warehouse: | CNBM Shanghai NO.6 |
| Product code: | SN_C4AB21E5E873 |
| Mini Order Qty: | 1 |
| Type: | |
| Drawing No.: | |
| Quantity: | - + EA |
| Remaining : | 100 |
| Shipping Cost: | To be confirmed |
| Add to Cart Add to Wishlist( 0 Adds) | |
Quick Details:
Technical Parameters
Electrical Specifications
Sensitivity: 100mV / g ± 10% (25 oC)
Frequency: 0.5 ~ 10,000 Hz (± 3dB)
High amplitude: 50g
Isolation: circuit and shell insulation
Noise: 0.0007g
Power: 2 ~ 10mA constant current, 18 ~ 30VDC
Bias threshold voltage: 10 ~ 14VDC
Resonance frequency: 30kHz
Maximum transmission distance: 300 meters
Environment and physical indicators
Temperature range: -50 oC ~ +120 oC
Protection class: IP67
Weight: 90 grams
Case Material: Stainless Steel
Mounting holes by: 1/4-28UNF
Installation torque: 29N * M
