Vibration Sensor | |
---|---|
Warehouse: | CNBM Shanghai NO.6 |
Product code: | SN_6A52A81AC1C2 |
Mini Order Qty: | 1 |
Type: | |
Drawing No.: | |
Quantity: | - + EA |
Remaining : | 100 |
Shipping Cost: | To be confirmed |
Add to Cart Add to Wishlist( 0 Adds) |
Quick Details:
Type: Vibration
Material: Metal
Physical properties of materials: conductors
Material Crystal structure: polycrystalline
Production process: integration
Output signal: digital type
Protection class: 1
Linearity: 1 (% F.S.)
Hysteresis: 1 (% F.S.)
Repeatability: 1 (% F.S.)
Sensitivity: 1
Drift: 1
Resolution: 1
Technical parameters:
1. Measuring amplitude: 0 ~ 2000um (peak-peak)
2. Frequency response: 4 ~ 300 Hz or 10 ~ 500 Hz
3. Sensitivity: 50mV/mm/s ± 5% or 20mV/mm/s ± 5%
4. Maximum Acceleration: 10g
5. Operating temperature: -30 ℃ ~ +120 ℃
6. Relative Humidity: less than 90%, non-condensing
7. Dimensions:. Φ35 × 78mm
8. fixing holes:. M10 × 1.5mm, 10mm depth
9. Sensitivity:. 20 ~ 50mV/mm/S ± 1% (based on user adjustment)
10. Frequency Response (optional): 5 ~ 100 Hz, 10 ~ 500 Hz, 10 ~ 1000 Hz
11. natural frequency: about 10Hz
12. Amplitude limit:. 2mm (peak - peak)
13. Maximum Acceleration: 10g
14. Installation: Vertical; horizontal; vertical, horizontal dual-use
